SE Electronics sE7 Small Diaphragm Cardioid Condenser Microphone with Clip
$109.00

Availability: In stock

Designed for drums, guitars, pianos, or indeed, any application requiring a pencil-mic design, the SE Electronics sE7 Small Diaphragm Cardioid Condenser Microphone with Clip is a back-electret, small-diaphragm condenser microphone. It sports a cardioid polar pattern. Fashioned from class-A circuitry and utilizing a transformer less output, the microphone captures sound with clarity and neutrality across its frequency response, thus eschewing overly harsh highs and aiding in a pleasurable bottom end.

A switchable 20 dB attenuation pad allows you to use this microphone with loud instruments, doing so with a favorable signal-to-noise ratio. A low-cut filter at 80 Hz helps filter out rumble and other unwanted bass issues. Thus, you can use the sE7 in both close and distant miking scenarios.

An all-metal chassis provides a robust, roadworthy construction, while gold-plated XLR terminations ensure security in the connecting process. A mic clip and a windscreen are included.
Description

Details

Designed for drums, guitars, pianos, or indeed, any application requiring a pencil-mic design, the SE Electronics sE7 Small Diaphragm Cardioid Condenser Microphone with Clip is a back-electret, small-diaphragm condenser microphone. It sports a cardioid polar pattern. Fashioned from class-A circuitry and utilizing a transformer less output, the microphone captures sound with clarity and neutrality across its frequency response, thus eschewing overly harsh highs and aiding in a pleasurable bottom end.

A switchable 20 dB attenuation pad allows you to use this microphone with loud instruments, doing so with a favorable signal-to-noise ratio. A low-cut filter at 80 Hz helps filter out rumble and other unwanted bass issues. Thus, you can use the sE7 in both close and distant miking scenarios.

An all-metal chassis provides a robust, roadworthy construction, while gold-plated XLR terminations ensure security in the connecting process. A mic clip and a windscreen are included.



SE Electronics sE7 Small Diaphragm Cardioid Condenser Microphone with Clip Features:


  • Optimized acoustic design, discrete class-A circuitry and a transformerless output
  • Clear, natural sound quality at all frequencies
  • Switchable -20dB attenuation pad
  • High sound pressure level (SPL) handling capability
  • Switchable low-cut 80 Hz filter
  • Extremely low-noise components



What's in the box

  • sE7 microphone
  • mic clip (with thread adapter)
  • wind screen



Product Specifications

Microphone

Sound Field Mono
Capsule Electret Condenser
Diaphragm 0.5" / 12.70 mm
Polar Pattern Cardioid
Circuitry Solid-State
Pad -20 dB
High-Pass Filter 80 Hz, 6 dB/Octave

Performance

Frequency Range 20 Hz to 20 kHz
Maximum SPL Cardioid: 136 dB SPL
Cardioid: 156 dB SPL
Impedance Cardioid: 200 Ohms
Load Impedance 1 Kilohms
Sensitivity Cardioid: 19 mV/Pa
Dynamic Range Cardioid: 120 dB
Cardioid: 140 dB
Signal-to-Noise Ratio Cardioid: 78 dB
Equivalent Noise Level Cardioid: 16 dB A-Weighted

Connectivity

Output Connectors (Analog) 1 x XLR 3-Pin
Power
Operating Voltage 48 V
Operating Current Consumption 3 mA

General

Brand  SE Electronics
Manufacture SKU sE7
UPC  819032011539
Dimensions ø: 0.91 x L: 4.72" / ø: 23 x L: 120 mm
Weight 4.52 oz / 128 g
